DESCRIPTION :
Torque (6.0V): 29 kg-cm / 402.7 oz-in
Torque (7.4V): 36 kg-cm / 499.9 oz-in
Torque (8.2V): 38 kg-cm / 527.7 oz-in
Speed: 0.117 s (6.0V) / 0.094 s (7.4V) / 0.085 s (8.2V)
Weight: 79.5 g (2.80 oz)
Dimension：40 x 20 x 38.8 mm
| SERVO SPECIFICATION : | |
| Stall Torque (kg-cm) | 29 (6.0V) / 36 (7.4V) / 38 (8.2V) |
| Stall Torque (oz-in) | 402.7 (6.0V) / 499.9 (7.4V) / 527.7 (8.2V) |
| No-load Speed | 0.117 s (6.0V) / 0.094 s (7.4V) / 0.085 s (8.2V) |
| Stall Current | 9.0A (6.0V) / 11A (7.4V) / 12A (8.2V) |
| Working Voltage | 6.0V ~ 8.4V DC Volts |
| Working Frequency | 1520μs / 333Hz |
| Dead Band | 0.001 ms (Default) |
| Bearing | 2x Ball Bearing |
| Gear | Metal Alloy Gear |
| Motor | Brushless Motor |
